SKU: WBIE023 Categories: , Brand:

SMA-F to N-M (Easy Install)

(1 customer review)

6



Share it:
Compare

SMA-F to N-M

Product Ref: WBIE023

SMA-M to N-F adaptor to join SMA Female and N-Male connectors.

Suitable for adding two panels / Omni distribution antennas a single Mobile booster and to extend its coverage parameter.

It can also be used with the Hiboost 3 series if extra antennas are required to be added to the booster.



Technical Parameters

 Insert hole Material Bronze
 Housing Material Brass
 Screw sleeve Material Brass
 Impedance 50Ω
 Frequency band DC-3GHz
 Rated operating voltage 335V
 Contact resistance:
 inner conductor≤ 3mΩ
 outer conductor≤ 2.5mΩ
Insulation resistance≥5000 MΩ
Medium withstand voltage1000V

Mechanical Characteristics

Inner conductor separation forceN>0.57N
Mechanical life>500 times (12 times per minute)
Connecting nut torqueSMA recommended 0.68~1.13N. m
Material of Coaxial CableRG187

Working Environment

Ambient temperature-55~155°C
Relative humidity95% at +40°C
